Signaling
The use of signals for controlling communications. (atis.org)
See Also: Signal, Signal Sources, Signal Processing, Signal Integrity, Signal Proccessing, Signal Analyzers, Signal Conditioning, Signal Generators, Signal Meters, Signal Conditioners
-
Product
Selective Field Analyzer
SFA-S
-
Active broadband isotropic antenna combined with portable USB powered spectrum analyzer. OFA-S/SE antenna has frequency response independent of antenna or electric field orientation. It offers broad dynamic range for the variety of RF regulatory, safety, EMC, wireless and telecommunications applications. Spectrum analyzer SA-S displays the frequencies and field strength of selected signals, allowing all results to be viewed and stored on PC.
-
Product
PXIe-4357 , 20-Channel, 24-Bit PXI Temperature Input Module
782118-01
Analog Input Module
20-Channel, 24-Bit PXI Temperature Input Module—The NI PXIe‑4357 input module provides integrated data acquisition and signal conditioning for 2‑, 3‑, or 4‑wire resistance temperature detector (RTD) measurements. It offers both high-speed and high-resolution modes. It provides per channel software-programmable configurations and automatically scale measured data into engineering units.
-
Product
Signal / Mini Power/ Mini Coax, Module, ITA, QuadraPaddle, iCon Series, 100/8 Position
510161102
ITA Module
Primary mating module 510160102. (May mate with other Receiver modules, as well.)
-
Product
10 MHz To 6 GHz LAN Wide Dynamic Range Average Power Sensor
L2051XA
Power Sensor
Frequency range of 10 MHz – 6 GHzLAN connectivity with a wide dynamic range of -70 to +26 dBm for small signal measurementsFast real-time measurement of 50,000 readings/secReal-time measurement with zero dead time to ensure every single continuous pulse is measuredAverage mode time-selectivity function allows full dynamic range for average and time selectivity average power measurementsInternal zero and automatic calibration saves time and reduces measurement uncertaintyA BenchVue software license (BV0007B) is now included with your instrument. BenchVue makes it simple to connect, control instruments, and automate test sequences
-
Product
Frequency Synthesizers
-
A frequency synthesizer allows the designer to generate a variety of output frequencies as multiples of a single reference frequency. The main application is in generating local oscillator (LO) signals for the up- and down-conversion of RF signals.
-
Product
Midi Logger
GL240
-
Its compact size contains an isolated input system which ensures that signals are not corrupted by inputs to other channels, thus eliminating wiring concerns. The GL240s multi-type inputs are suitable for voltage, temperature, humidity, pulse, and logic signals, enabling combined measurements of different phenomena like temperature/humidity and voltage. power ground allowing off-ground measurements using shunts, as well as powered or grounded thermocouples.
-
Product
Isolated Digital I/O Card
PCIe-IDIO-24
-
This product is a x1 lane PCIe isolated digital input and FET output board with Change of State (COS) detection capabilities. In addition to the isolated signals, 8 (or 4) TTL/CMOS input/output pins are available, for your application’s convenience.
-
Product
LXI Microwave Multiplexer, SP6T, 6-Bank, 26.5GHz, 50Ω, SMA
60-800-306
Microwave Multiplexer
Our 60-800-306 is a 6 bank terminated SP6T multiplexer and is part of a range of LXI based microwave multiplexers suitable for switching 50 ohm signals up to 26.5GHz. The 60-800 range is capable of supporting up to 14 banks of 6 channel terminated multiplexers and is ideal for constructing complex microwave switching systems for many applications. Connection is by high performance front panel mounted SMA, SMA-2.9, SMA-2.4 or SMA-1.85 connectors.
-
Product
Talon 8 Channel 6 GHz RF Rugged Rackmount Recorder
Talon RTR 2628
-
- Eight-channel phase-coherent RF recording- Ideal for signal intelligence, phased-array radars, beamforming, and DF (Direction Finding) systems- Records RF frequencies from 30 MHz to 6 GHz- Captures 80 MHz of instantaneous bandwidth- Eight-channel RF tuner can be set for phase-coherent operation or independent tuning- Eight 250 MHz 16-bit A/Ds- Eight DDCs with decimations to 65,536 for selectable bandwidths- 3.2 GB/sec real-time aggregate recording rate- 4U 19-inch rugged rackmount PC server chassis- Windows® workstation with high performance Intel™ processor- Front panel removable SSD drives- Up to 122 terabytes of storage to NTFS RAID disk array- SystemFlow® GUI with signal viewer analysis tool- Optional GPS time and position stamping
-
Product
LXI Optical Switching - 16x16 Matrix Plugin Module
65-280-314
Matrix Switch Module
The 65-280-314 16x16 matrix is part of the 65-280 and 65-281 ranges of optical plug-in modules offering matrix & insert/bypass or multiplexer & SPST topologies respectively with all models based on MEMS fiber optic switches and available in various populations per plugin. In addition, a choice of different connector styles to suit most applications is offered: FC/APC (for optimal performance), FC/PC, SC/PC and ST for general applications and LC for high density applications. They use MEMS (Micro-Electro-Mechanical-Systems) based optical switches to route signals between terminals by redirecting the optical signal. This is achieved using micromechanical mirrors driven by a highly precise mechanism activated via an electrical control signal.
-
Product
Analysis Tool for ECU Networks and Distributed Systems
CANape
-
The primary application area of CANape is in optimizing parameterization (calibration) of electronic control units. During a measurement process, you can simultaneously calibrate parameters and record signals. The communication between CANape and the ECUs takes place via protocols such as XCP or via microcontroller-specific interfaces with the VX1000 measurement and calibration hardware. CANape supports various ADAS sensors such as radar, LIDAR and video. Combined with high-performance hardware, CANape can store multiple gigabytes of data per second. Calibration data management and convenient measurement data evaluation including data management as well as reporting make CANape a complete tool for ECU calibration. Of course, CANape also provides access to bus data, diagnostic data and analog measurement data.
-
Product
Data Acquisition Device A2D / D2A
-
General Features10 DAC channels5 ADC channelsDifferential or single ended IOs Full scale bipolar or unipolar signaling
-
Product
Talon 3.6 GS/sec Ultra Wideband RF/IF Rugged Portable Recorder
Talon RTR 2729A
-
- Video: A Quick Look at RTR 2729A Talon Rugged Portable Recorder- Designed to operate under conditions of shock and vibration- Portable system measuring 16.0" W x 6.9"D x 13.0" H- Lightweight, just less than 30 pounds- Sample rates up to 3.6 GHz in single-channel mode- Sample rates up to 1.8 GHz in dual-channel mode- 12-bit A/D, with 16- and 8-bit packing modes- Capable of recording RF/IF frequencies to 1.75 GHz in single-channel mode- Capable of recording RF/IF frequencies to 2.8 GHz in dual-channel mode- Real-time sustained recording rates of up to 4.0 GB/sec- Windows® 7 Professional workstation with high-performance Intel® Core™ i7 processor- Up to 61.4 terabytes of SSD storage to NTFS RAID solid state disk array- SystemFlow® GUI with Signal Viewer analysis tool- Optional file headers include time stamping and recording parameters- Optional GPS time and position stamping- Optional 10-36 VDC power supply
-
Product
Unified Satellite Phone Monitoring System
-
Unified Satellite Phone Monitoring System is designed to intercept Voice, SMS and Text traffic from Satellite Phones operating on Thuraya, Iridium and IsatPhone Pro Satellite networks. The system is pre-integrated & pre-configured in a compact ruggedized transportable casing for plug and play operations. It intercepts the signals from L-band uplink (from Satellite Phones to Satellites) and downlink (from Satellite to Satellite Phones) to provide the duplex calls up to 15 Kms with LOS and beyond that simplex calls. System is equipped state-of-the-art high performance Thuraya and IsatPhone Pro decryption module , Iridium proprietary protocol module to provide processed intelligible output in the form of Voice, SMS and Text along with session related information such as Called Phone Number (for session initiated by Satellite Phone),Caller ID, TMSI/IMSI/IMEI and geo-location
-
Product
USB-based Digital Oscilloscope
DSCope Series
-
DSCope is small(115mmx74mmx16mm), and can be packed in a shirt pocket. Combined with big screen and powerful performance computer, DSCope series oscilloscope can provide you amazing signal capture and analyzer experience.
-
Product
15-CH Isolated Digital Output Module
ND-6056
Data Acquisition Module
ADLINK's NuDAM data acquisition modules make up a total acquisition network and control system. Up to 256 NuDAM modules an be romotely controlled on any RS-485 network from a host computer, via a single serial RS-232, allowing communication from as far as 4000 feet from the host. Based on the RS-485 multi-drop network system, each module has a unique address ID, whereby simple ASCII command & response protocols through the standard RS-485 interface can control all the NuDAM modules in the RS-485 network. The NuDAM modules provide direct communications with a wide variety of sensors, perform all signal conditioning, scaling, linearization and conversion, and can acquire measurements of temperature, pressure, flow, voltage, current, and multiple digital signal types.
-
Product
Handheld Cable Fault Locator
TM800H
-
TM800H Handheld Cable Fault Locator adopts TDR (Time Domain Reflection), new signal process and data collection technology. It can locate the distance of cable break and mix faults accurately. TM800H can be widely used in the communication installation, maintenance and general wiring. It can troubleshoot not only the local Telco-cable, but also Network cable. Its high sampling rate makes the measurement dead zone as narrow as 1 meter. This makes it a straightforward, user-friendly test solution.
-
Product
Government R&D
-
Hyperion Technology Group, Inc.
Sensor engineering and signal processing for defense, intelligence, and national security including sensor engineering and signal processing for detect and track of unauthorized aircraft, acoustic sensing and sensor fusion for protection of forward operating base perimeters, sensor engineering and signal processing to detect and locate live weapons fire, infrasound sensing and signal processing to geolocate counter-fire, and more.
-
Product
Saluki SE2031 DSP Lock-In Amplifier
-
SE2031 Digital Lock-in Amplifier provides an excellent performance within its bandwidth from 1 mHz to 10 MHz. With the advantage of the latest digital signal processing technology and high-speed 16-bit ADC, SE2031 can easily detect the phase and the magnitude of weak signals overwhelmed by various large noise. The performance of SE2031 is as good as other lock-in amplifier brands, even better in some certain parameters, such as measurement accuracy, SNR, dynamic reserve. Otherwise, SE2031 integrates some special functions like multiple harmonic measurement, which meets the needs of scientific research and industrial application well.
-
Product
IP67 DC Blocking Splitter Combiner
PD5033
-
INSTOCK Wireless Components, Inc
PD5033 is an IP67 outdoor, weather resistant, DC blocking, three way, RF broadband, 50 ohm, power divider, power combiner furnished with N type coaxial connectors. The passive Wilkinson design passes RF and the 10 MHz reference signal through both ports while blocking DC current. This configuration is typically used in combining applications to prevent passing DC to the sum and adjacent ports. Max voltage rating at the DC blocked ports is 50 VDC. All wireless band applications in the frequency range from 698 to 2700 MHz are covered with best in class RF performance. The RoHS compliant PD5033 is a bidirectional device capable of 40 W max microwave input power levels in both power splitter and combiner apps. See 3 way power divider input rating tables for additional power handling info.
-
Product
20GHz Single Channel MW Benchtop Signal Generator
LSX2091B
Signal Generator
The LSX2091B is a 20GHz Single Channel Microwave Signal Generator, offers industry leading performance, in an easy to use benchtop box. It features exceptionally fast switching speed, superior signal integrity and purity and all the necessary modulated signals for analog communication systems. The design offers excellent performance and abilities combined with an affordable price tag, needed from the R&D benches to the production lines.
-
Product
VME / VSB Module
ADM-42M
-
The AD42M Data Acquisition Module provides high performance 14-bit digitizing of analog signals for VMEbus applications. The AD42M accepts 4 differential analog inputs via front panel miniature SMC connectors. The AD42M utilizes a signal processor to acquire and store data samples. The AD42M is able to direct the data samples to local static RAM or VSB.
-
Product
LXI Microwave Multiplexer, SP4T, 14-Bank, 50GHz, 50Ω, SMA-2.4
60-803-614
Multiplexer Module
Our 60-803-614 is a 14 bank SP4T multiplexer and is part of a range of LXI based microwave multiplexers suitable for switching 50 ohm signals up to 50GHz. The 60-803 range is capable of supporting up to 16 banks of 4 channel multiplexers it is ideal for constructing complex microwave switching systems for many applications. Connection is by high performance front panel mounted SMA, SMA-2.9, SMA-2.4 or SMA-1.85 connectors.
-
Product
Media Gateway
-
A Media Gateway is a networking device that provides valuable and essential functions for organizations, service providers, and network operators. When interconnecting traditional time-division-multiplexed (TDM) telephony systems with modern voice-over-internet protocol (VoIP) systems, a VoIP media gateway works by providing protocol conversion (translation) and interoperability between the two network technologies. Also known as an IP media gateway or SIP media gateway, the device converts a traditional analog plain-old-telephone-system (POTS) voice signal or related digital telephony signals such as T1, DS3, STM1 or OC3 into packets for transmission over a data network such as the Internet, private IP Network or a corporate LAN. When the legacy system is based on digital integrated services digital network (ISDN) technology, the device may be called a digital VoIP gateway or ISDN media gateway. Some manufacturers combine gateway functionality with WAN-access (internet-access) capability into a single device or network appliance. Such a dual-purpose device may be known as an access media gateway.
-
Product
Tactical Grade Inertial Measurement Unit (IMU)
ADIS16490 iSensor
-
The ADIS16490 iSensor® device is a complete inertial system that includes a triaxial gyroscope and a triaxial accelerometer. Each inertial sensor in the ADIS16490 combines industry-leading iMEMS® technology with signal conditioning that optimizes dynamic performance. The factory calibration characterizes each sensor for sensitivity, bias, alignment, and linear acceleration (gyroscope bias). As a result, each sensor has its own dynamic compensation formulas that provide accurate sensor measurements. The ADIS16490 provides a simple, cost-effective method for integrating accurate, multiaxis inertial sensing into industrial systems, especially when compared with the complexity and investment associated with discrete designs. All necessary motion testing and calibration are part of the production process at the factory, greatly reducing system integration time. Tight orthogonal alignment simplifies inertial frame alignment in navigation systems. The SPI and register structure provide a simple interface for data collection and configuration control.
-
Product
Comb Generators
-
Keysight comb generators provide excellent phase and amplitude flatness making them ideal for use in phase calibration applications. A customer selectable USB-controlled frequency divider which allows for broad range of input signal frequencies from 10 MHz to 67 GHz and small minimum tone spacing of 10 MHz, makes Keysight comb generators suitable for characterizing non-linear devices.
-
Product
GNSS Signal Generation System
GSS6300
-
The Spirent GSS6300 has been specifically designed to facilitate high-volume production testing for GNSS-enabled applications. Capable of generating a single channel of multiple GNSS in the L1 band individually or concurrently, the GSS6300 offers the fidelity and reliability needed for final functional testing of high-value critical systems.
-
Product
GHZ-Wideband Amplifiers
-
Ultra-wide bandwidth from 10 kHz up to 2.5 GHzGain up to 60 dB (x 1,000)Transimpedance gain with photodetectors up to 50,000 V/AVery low input noise down to 310 pV/√Hz (6.2 pA/√Hz)Integrated DC-current path for biased photodetector applicationsTwo identical signal outputs (HSA-Y series)DC-monitor output (HSA-Y series)
-
Product
PXI High Density Mux 24 Channel 4 Pole
40-670A-021-24/4
Multiplexer Module
The 40-670A series of very high density multiplexer modules feature a wide range of switching configurations. Typical applications include signal routing in ATE and data acquisition systems. The 40-670 multiplexer may be operated as a conventional multiplexer with break-before-make action when a new channel is selected. In addition multiple channels may be simultaneously selected (not available in 1 pole mode).
-
Product
Ground Fault Finder
FST-JD200 DC
-
Foresight Electronics Co., Ltd.
FST-JD200 not only can provide a solution on accurately testing the faults of the indirect-grounding of the direct current system, non-metal grounding, loop grounding, simultaneous grounding of the anode and cathode, balanced grounding of the anode and cathode and multi-point grounding 1. The high-precision sampling clamp meter The device uses a high resolution (0.1mA) signal sampling direct current clamp meter that can achieve multi-point grounding and high resistance ground point positioning...
